Description
Motion sensors use passive infra-red (PIR) technology to monitor for a variety of different needs. The 60° beam width is best for use in typical security types of monitoring. Human bodies or med/large sized animals can be detected at a range of up to 5 meters, alerting you when someone (or something) is where it shouldn’t be. Use the 100° version of the sensors for tracking applications. Designed to be placed under a desk, a cubicle, a conference room table, the sensor can be implemented by companies as part of room scheduling and space booking programs, showing what desks are available/unoccupied within a building, how effectively space is being utilized or underutilized, etc. 1,200+ foot range 12+ year battery life 80+ wireless sensors Bank-level AES security Up in 15 easy setup Global ready (900, 920, 868 & 433 MHz) Current Consumption: Type: 170 µA Max: 300 µA Wake-up Time: 30 Seconds Sensing Range: 15 ft (4.5 m)/12 ft (3.7 m)/9 ft (2.7 m) Security: Encrypt-RF® (256-bit key exchange and AES-128 CTR) Weight: 2.9 oz. (82.21 g) Supply Voltage: 2.0–3.8 VDC (3.0–3.8 VDC using power supply) Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F) Data Logging (iMonnit Premiere): Datalogs 2000 to 4000 readings if gateway connection is lost (non-volatile flash, persists through the power cycle): 10-minute heartbeats = ~ 22 days2-hour heartbeats = ~ 266 days Sensing Method: Quad Array Passive Infrared (PIR) Sensing Element Response Time: 1 to 3 Seconds Storage Temperature:: -40°C to 85°C (-40°F to 185°F) Visual Confirmation: Standard LensViewing Angle: 60°Range: 15ft (4.57m)/12ft (3.65 m)/9ft. (2.74 m) Visual Confirmation: Wide-Angle LensViewing Angle: 100°Range: 15ft. (4.57m)/12ft. (3.65m)/9ft. (2.74m) Battery Type: 2 Replaceable AA 1.5 V Batteries Dimension: 4.375 in x 2.470 in x 1.12 in Supply Voltage: 2.0 - 3.8 V (2 x AA 1.5V Batteries or Optional Power Supply) Battery Life: At 1 hour heartbeat setting, AA batteries will last up to 10 years.** Max Operating Temperature Using AA Alkaline: -18°C to 55°C (0°F to 130°F) Max Operating Temperature Using AA Lithium: -40°C to 60°C (-40°F to 140°F) Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F) Enclosure Material: ABS Operating Frequency: 900 MHz Operating Frequency Certifications: Complies with Part 15 of the FCC Rules. (FCC ID: ZTL-G2SC1)Complies with Industry Canada standards. (IC: 9794A-G2SC1) Device Range: Device Range Up to 1,200 ft. non-line-of-sight, wireless device range* Security: Encrypt-RF® (Diffie-Hellman Key Exchange + AES-128 CBC)
Monnit MNS2-9-W2-MS-IR Features
Infrared Motion Sensing Element Specifications
Variation Specifications
ALTA AA Specifications
ALTA 900 MHz Specifications
